Model No.: WTST20
Brand: 3Grace
warranty period: 3months-1year
Custom processing: Yes
place of origin: China
Chassis style: Wall Socket
Grounded: Gfci
Scope of application: Commercial, Industrial, Hospital, Residential / General-Purpose
| Selling Units: | Piece/Pieces |
| Package Type: | Carton |
| Picture Example: |
|
3Grace Trimone is the first GFCI manufacturer who successfully makes the GFCI Outlet cannot be reset if the circuit no longer provides ground fault protection. In addition, this 20 Amp Weather Resistant auto trip Gfci Outlet have a built-in line-load reversal feature that prevents the GFCI from resetting if the installer mistakenly reverses the load and line connections.
Product Specification
Model: WTST20 | |
Electrical Specifications | |
Self Testing | Yes |
Amperage | 20 Amp |
Rated Voltage | 125 VAC |
Rated Frequency | 60 Hz |
Pole | 2 |
Wire | 3 |
Grounding | Self Grounding With Grounding Clip |
Short Circuit Current Rating | 10KA |
Trip Level | Class A, 6mA plus or minus 4mA |
Trip Time | <25ms |
Material Specifications | |
Body Material | PC-Thermoplastic Flammability UL-94 V2 Rating |
Face Material | PC-Thermoplastic Flammability UL-94 V2 Rating |
Terminal Screws | Plated Steel |
Grounding Screw | Plated Steel |
Yoke | Zinc-Plated Steel |
Mechanical Specifications | |
Terminal ID | Brass-Hot, Green-Ground, Silver-Neutral |
Terminal Wire applied | 14-12 AWG |
Tamper Resistant | Yes |
Weather Resistant | Yes |
Termination | Back & Side |
Environmental Specifications | Operating Temperature: -35℃ to +66℃ |
Applicable Standards | UL/CUL UL498/UL943 |
Warranty | 2-Years |
Our advantage:
1. With more than 20years experiences in cost control, which enable us to be competitive in the low voltage electrical products market.
2. To meet the quality target of UL standard, the complete inspection will be conducted for every order and also samples
3. Professional Team – consist of engineer, production manager, and skillful workers, to serve our customer with better service.
4. with its 20 years manufacturing experience in low voltage electric product filed, the first Chinese GFCI manufacturer.
Product Application:
A 20 Amp Weather Resistant auto trip GFCI Outlet normally is installed in any potentially wet or damp places. Wet places can make the possibility to dangerous electric shock higher but applying a GFCI receptacle can greatly reduce your risk of injury.
FAQ:
Question: Will these work if wired without a ground wire?
Answer: Dear customer, this item is a ground fault circuit interrupter, if wiring without the grounding wire，it will loss protection function.
Question: If i am not sure about the amps of my circuit (15a vs 20a), is it safer to just use with the 15Amp outlet?
Answer: it does not matter, it's ALWAYS OK to put a 15A outlet on a 20A circuit.
Question: If the upstream gfci is 15Amp, would the downstream gfci have to be in 15Amp?
Answer: If you already have an upstream GFCI and it is wired in a correct way, no need a downstream GFCI any more, as a well-wired GFCI protects all downstream circuits.
Packaging:
Below GFCI packaging for your reference
Customized packaging available
Quality Control
Product Quality is one of the most important factor both manufacturer and consumer consider about. Trimone have taken great importance to the quality control to make our products relieble. The reliability is achieved throught the UL approved testing system that ensure every outgoing product with good quality.
