Zhejiang Trimone Technology Co., Ltd
| Payment Type: | T/T,Paypal |
| Incoterm: | Ocean,Land,Air,Express |
| Min. Order: | 1 Piece/Pieces |
| Transportation: | Ocean,Land,Air,Express |
Model No.: TS15
Brand: 3 Grace
warranty period: 3months-1year
Custom processing: Yes
place of origin: China
Chassis style: Wall Socket
Scope of application: Industrial, Commercial, Hospital, Residential / General-Purpose
Grounded: Gfci
Certification: UL
Operating Humidity: 30-93%
Material: PC+copper
Current: 120V AC
Auto-Monitoring Function: 1s
OperatingTemperature: -35℃ to 66℃
Trip Time: 0.0255s
Flamma bility: Rated V-2 per UL 943
size: 105*44.6*42.6mm
Weight: 123.5g(without wallplate)
| Selling Units: | Piece/Pieces |
| Package Type: | 1pc with color box, 10pcs with white box, 50pcs/carton or 100pcs/carton or Customized |
| Picture Example: |
|
Features:
1. 15 Amp 125VAC, 60Hz feed through
2. Back and side wired
3. Red/ Bule/black button or at your option
4. Molded TR on the face cover, with TR GFCI Outlet safety for Children
3Grace Gfci Outlet Advantages
1. Professional original factory, 20 years focus on manufacturing GFCI outlet experiences
2. Prevent electrical shock by accidental
3. Prevent electrical fires.
4. Suitable for a variety of occasions
Specifications:
Input Voltage | 125 V |
Frequency | 60 Hz |
Front Receptacle Current | 15 Amp |
Pass Through Current | 20 Amp |
Trip Fault Current | 4-6 mA |
Trip Time | 0.025 Seconds |
Auto-Monitoring Function Test Power-up Test Interval | 1 Seconds |
Auto-Monitoring Function Test Repeat Test Interval | 1-10 Minutes |
Auto-Monitoring Function Test Detection and EOF LED Flash Rate | 0.1-3 Hz |
Accepted Terminal Wire Size | 12 gauge to 14 gauge |
Wiring Type | Rear pressure plate and side wiring |
Flammability | Rated V-2 per UL 943 |
Operating Temperature | -35℃ to 66℃ |
Operating Humidity | 30-93% |
Applications
Packing
Shipping
FAQ:
Q1. How to get a sample ?
A1: Confirm the model & cost--make payment---prepare samples---delivery parcel---Got samples!
Q2: How Long is your delivery time?
A2: It’s depend on your order. For the sample, generally it is will take 2-5 days after receive the payment. For the Bulk order, it is will take 15-25days after receive the payment.
Q3: How to get your price list ?
A3: There are many models in our site, in order to offer most competitive price to you, Please kindly advice Model No or requirement and Target Quantity to us, then the best offer will be arrived in your side within half hours!
After sales service:
A. Support free installation guidance through pictures or video
B. Free repair for quality problem products within warranty period
C. Warranty: 12 months since dispatch the goods
D. Reply customers request within 24 hours
